Specification

630(8P)

800(10p)

1000(13p)

Rated Capacity(kg)

630

800

1000

Shape

semi-circle
squareness
diamond

semi-circle
squareness
diamond

semi-circle
squareness
diamond

Speed(m/s)

1.0  1.75

1.0  1.75

1.0  1.75

Control System

Full collective operation

Driving Type

VVVF Driving

Door Machine

VVVF Door control

Motor Type

PM/Gearless

Communication

Serial Communication

Car Size
(width*depth*height)

1100*1600*2350
1100*1400*2350
1100*1600*2350

1100*1600*2350
1100*1400*2350
1100*1600*2350

1100*1600*2350
1100*1400*2350
1100*1600*2350

Door Opening Size
(width*height)

800*2100

800*2100

900*2100

Travel Height

≤90m

≤90m

≤90m

Top Floor

32/32

32/32

32/32

Hoistway Size
(width*depth)

2000×2050
2000×1850
2000×2050

2100×2050
2100×1950
2100×2050

2400×2150
2400×1850
2400×2150

Motor Position

Above Shaft

Overhead

4400 4600 4300
4500 4300 4500

4400 4600 4300
4500 4300 4500

4400 4600 4300
4500 4300 4500

Pit depth

1700 1850 1500
1650 1600 1750

1800 1950 1500
1650 1600 1750

1900 2050 1500
1650 1600 1750

Motor Rated Capacity(KW)

4.37 7.66 4.37
7.66 4.37 7.66

5.36 9.38 5.36
9.38 5.36 9.38

6.75 11.8 6.75
11.8 6.75 11.8

Rated Current(A)

9.8 19.2 9.8
19.2 9.8 19.2

11.86 20.6 11.86
20.6 11.86 20.6

14.95 26.3 14.95
26.3 14.95 26.3

Rated Current(A)

380V,50HZ 3phase,5wire
